Texas Instruments SimpleLink CC3220MOD Series Manual page 88

MOB0063A
2X
19.05
NOTES:
1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing
per ASME Y14.5M.
2. This drawing is subject to change without notice.
A
PIN 1 INDEX
AREA
2X (0.45)
2X (0.38)
2.40
2.03
0.88
0.72
30X 1.27
17
16
15
2 0.05
1.5
57
56
6X 3
55
2
1
54
PIN 1 ID
(45 X1)
6X 3
SCALE 0.650
17.75
17.25
2X 12.7
20X 1.27
27
28
29
(0.3)
TYP
9X
60
63
59 62
61
58
42
44 43
1.5
www.ti.com
PACKAGE OUTLINE
QFM - 2.4 mm max height
QUAD FLAT MODULE
B
20.75
20.25
C
0.1
(0.3) TYP
(0.32)
PADS 1,16,28 & 43
54X 0.81 0.08
0.15 C A B
0.05 C
4221462/D 06/2019
