8.9 CC3220MODAx Antenna Characteristics

T = 25°C
A
PARAMETER
Polarization
Peak Gain
Efficiency

8.10 WLAN Receiver Characteristics

T = 25°C, V = 2.3 V to 3.6 V. Parameters measured at module pin on channel 6 (2437 MHz).
A BAT
PARAMETER
Sensitivity
(8% PER for 11b rates, 10% PER for 11g or 11n rates)
(1)
(10% PER)
Maximum input level
(10% PER)
(1) Sensitivity is 1-dB worse on channel 13 (2472 MHz).

8.11 WLAN Transmitter Characteristics

T = 25°C, V = 2.3 V to 3.6 V. Parameters measured at module pin on channel 6 (2437 MHz)
A BAT
PARAMETER
Max RMS Output Power measured at 1 dB
from IEEE spectral mask or EVM
Transmit center frequency accuracy
(1) The edge channels (2412 MHz and 2462 MHz) have reduced TX power to meet FCC emission limits.
(2) Power of 802.11b rates is reduced to meet ETSI requirements.

8.12 Reset Requirement

V Operation mode level
IH
V Shutdown mode level
IL
Minimum time for nReset low for resetting the module
T and T Rise and fall times
r f
(1) The nRESET pin must be held below 0.6 V for the module to register a reset.
Copyright © 2021 Texas Instruments Incorporated
TEST CONDITIONS
2450 MHz
2450 MHz
1 DSSS
2 DSSS
11 CCK
6 OFDM
9 OFDM
18 OFDM
36 OFDM
54 OFDM
MCS7 (mixed mode)
802.11b
802.11g
1 DSSS
2 DSSS
11 CCK
6 OFDM
9 OFDM
18 OFDM
36 OFDM
54 OFDM
MCS7 (mixed mode)
PARAMETER
(1)
Product Folder Links:
SWRS206E – MARCH 2017 – REVISED MAY 2021
RATE
RATE
MIN
0
5
CC3220MOD CC3220MODA
CC3220MOD, CC3220MODA
MIN TYP MAX
Linear
2.5
70%
MIN TYP MAX
–95.0
–93.0
–87.0
–89.5
–89.0
–85.5
–79.5
–73.5
–69.5
–3.0
–9.0
(1) (2)
.
MIN TYP MAX
17.0
17.0
17.3
16.3
16.3
16
15
13.5
12
–20 20
TYP MAX
0.65 × V
BAT
0.6
20
Submit Document Feedback
UNIT
dBi
UNIT
dBm
dBm
UNIT
dBm
ppm
UNIT
V
V
ms
µs
35
