CC3220MOD, CC3220MODA
SWRS206E – MARCH 2017 – REVISED MAY 2021

13 Mechanical, Packaging, and Orderable Information

The following pages include mechanical, packaging, and orderable information. This information is the most
current data available for the designated devices. This data is subject to change without notice and revision of
this document.

13.1 Mechanical, Land, and Solder Paste Drawings

The total height of the module is 2.45 mm.
The weight of the CC3220MODx module is 0.00175 kg ±3%.
The weight of the CC3220MODAx module is 0.00206 kg ±3%
1. All dimensions are in mm.
2. Solder mask should be the same or 5% larger than the dimension of the pad
3. Solder paste must be the same as the pin for all peripheral pads. For ground pins, make the
solder paste 20% smaller than the pad.

13.2 Package Option Addendum

The CC3220MOD is only offered in a 750-unit reel. The CC3220MODA is only offered in a 600-unit reel.
