Table 8-7 lists the timing parameters for the I2S receive mode.
ITEM NAME
(1)
T1 f
clk
LP (1)
T2 t
(1)
T3 t
HT
(1)
T4 t
OH
(1)
T5 t
OS
(1) Timing parameter assumes a maximum load of 20 pF.
8.14.5.3 GPIOs
All digital pins of the module can be used as general-purpose input/output (GPIO) pins. The GPIO
module consists of four GPIO blocks, each of which provides eight GPIOs. The GPIO module supports 24
programmable GPIO pins, depending on the peripheral used. Each GPIO has configurable pullup and pulldown
strength (weak 10 µA), configurable drive strength (2, 4, and 6 mA), and open-drain enable.
Figure 8-12 shows the GPIO timing diagram.
V
80%
20%
Table 8-8 lists the GPIO output transition times for V
DRIVE DRIVE STRENGTH
STRENGTH (mA) CONTROL BITS
2MA_EN=1
2
4MA_EN=0
2MA_EN=0
4
4MA_EN=1
2MA_EN=1
6
4MA_EN=1
(1) V = 2.3 V, T = 25°C, total pin load = 30 pF
BAT
(2) The transition data applies to the pins other than the multiplexed analog-digital pins 25, 26, 42, and 44.
