Texas Instruments SimpleLink CC3220MOD Series Manual page 85

MON0063A
PIN 1 ID
19.61 0.1
PICK & PLACE
NOZZLE AREA
2.40
2.03
0.88
0.72
30X 1.27
2X
19.05
PADS 1-16
& 28-43
6X 3
PIN 1 ID
(45
(0.326) TYP
NOTES:
1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing
per ASME Y14.5M.
2. This drawing is subject to change without notice.
A
16.74 0.1
2X 12.7
20X 1.27
17
16
15
9X
2 0.05
1.5
60
57
56
59
55
58
X1)
2
1
54
6X 3
11.769
PACKAGE OUTLINE
QFM - 2.4 mm max height
SCALE 0.600
25.25
24.75
PKG
27 28
29
63
62
61
42
44
43
54X 0.81
2.224
0.15
4.321
0.05
www.ti.com
QUAD FLAT MODULE
B
20.75
20.25
C
PKG
19.038
PADS 17-27
& 44-54
0.08
C A B
C
4223415/C 06/2019
