9.7.1.4 Memory Map
Table 9-4 describes the various MCU peripherals and how they are mapped to the processor memory. For more
information on peripherals, see the API document.
START ADDRESS
0x0000 0000
0x0100 0000
0x2000 0000
0x2200 0000
0x4000 0000
0x4000 4000
0x4000 5000
0x4000 6000
0x4000 7000
0x4000 C000
0x4000 D000
0x4002 0000
0x4002 4000
0x4002 0800
0x4003 0000
0x4003 1000
0x4003 2000
0x4003 3000
0x400F7000
0x400F E000
0x400F F000
0x4200 0000
0x4401 0000
0x4401 8000
0x4401 C000
0x4402 0000
0x4402 1000
0x4402 5000
0x4402 6000
0x4402 D000
0x4402 E000
0x4402 F000
0x4403 0000
0x4403 0000
0x4403 5000
0x4403 7000
0x4403 9000
0xE000 0000
0xE000 1000
0xE000 2000
0xE000 E000
56 Submit Document Feedback
Table 9-4. Memory Map
END ADDRESS
0x0007 FFFF On-chip ROM (bootloader + DriverLib)
0x010F FFFF On-chip Flash (for user application code)
0x2003 FFFF Bit-banded on-chip SRAM
0x23FF FFFF Bit-band alias of 0x2000 0000 to 0x200F FFFF
0x4000 0FFF Watchdog timer A0
0x4000 4FFF GPIO port A0
0x4000 5FFF GPIO port A1
0x4000 6FFF GPIO port A2
0x4000 7FFF GPIO port A3
0x4000 CFFF UART A0
0x4000 DFFF UART A1
2
0x4000 07FF I C A0 (master)
0x4002 4FFF GPIO group 4
2
0x4002 0FFF I C A0 (slave)
0x4003 0FFF General-purpose timer A0
0x4003 1FFF General-purpose timer A1
0x4003 2FFF General-purpose timer A2
0x4003 3FFF General-purpose timer A3
0x400F 7FFF Configuration registers
0x400F EFFF System control
0x400F FFFF µDMA
0x43FF FFFF Bit band alias of 0x4000 0000 to 0x400F FFFF
0x4401 0FFF SDIO master
0x4401 8FFF Camera Interface
0x4401 DFFF McASP
0x4402 0FFF SSPI
0x4402 1FFF GSPI
0x4402 5FFF MCU reset clock manager
0x4402 6FFF MCU configuration space
0x4402 DFFF Global power, reset, and clock manager (GPRCM)
0x4402 EFFF MCU shared configuration
0x4402 FFFF Hibernate configuration
Crypto range (includes apertures for all crypto-related
0x4403 FFFF
blocks as follows)
0x4403 0FFF DTHE registers and TCP checksum
0x4403 5FFF MD5/SHA
(1)
0x4403 7FFF AES
(1)
0x4403 9FFF DES
0xE000 0FFF Instrumentation trace Macrocell
0xE000 1FFF Data watchpoint and trace (DWT)
0xE000 2FFF Flash patch and breakpoint (FPB)
0xE000 EFFF NVIC
