Connecting Cables to MHO-175
In This Section:
Connecting to the Management Port with DAC or Fiber Cables
Connecting to the Management Port with Breakout Cables
Connecting to the Uplink Ports with DAC or Fiber Cables
Connecting to the Uplink Ports with Breakout Cables
Connecting to the Downlink Ports with DAC or Fiber Cables
Notes:
The different diagrams below show connections to different ports on the Quantum Maestro
n
Orchestrators.
It is possible to connect to the Quantum Maestro Orchestrator ports with a DAC cable, Fiber cable
n
(with transceivers), or Breakout cable.
The sections below provide a high-level description.
n

Connecting to the Management Port with DAC or Fiber Cables

Important - When you connect two Quantum Maestro Orchestrators for redundancy, the
Check Point Management Server connects only to one of the Quantum Maestro
Orchestrators.
Example:
Connecting Cables to MHO-175
Quantum Maestro Getting Started Guide | 98
