Explanations:
Table: Explanations
Item Description
1 The first Quantum Maestro Orchestrator.
2 The second Quantum Maestro Orchestrator.
3 A 100 GbE DAC cable connected to the dedicated Synchronization ports on the Quantum
Maestro Orchestrators.
Important - This connection is only used to synchronize the configuration of Security
Groups between the Quantum Maestro Orchestrators.
4 A DAC cable or Fiber cable (with transceivers) connected to a Downlink port (in our example,
Port 20) on the first Quantum Maestro Orchestrator (1) and to the applicable port on the
Expansion Line Card on the Security Appliance 16.
5 A DAC cable or Fiber cable (with transceivers) connected to a Downlink port (in our example,
Port 20) on the second Quantum Maestro Orchestrator (2) and to the applicable port on the
Expansion Line Card on the Security Appliance 16.
6 A DAC cable or Fiber cable (with transceivers) connected to a Downlink port (in our example,
Port 22) on the first Quantum Maestro Orchestrator (1) and to the applicable port on the
Expansion Line Card on the Security Appliance 15.
7 A DAC cable or Fiber cable (with transceivers) connected to a Downlink port (in our example,
Port 22) on the second Quantum Maestro Orchestrator (2) and to the applicable port on the
Expansion Line Card on the Security Appliance 15.
8 A DAC cable or Fiber cable (with transceivers) connected to a Downlink port (in our example,
Port 24) on the first Quantum Maestro Orchestrator (1) and to the applicable port on the
Expansion Line Card on the Security Appliance 13.
9 A DAC cable or Fiber cable (with transceivers) connected to a Downlink port (in our example,
Port 24) on the second Quantum Maestro Orchestrator (2) and to the applicable port on the
Expansion Line Card on the Security Appliance 13.
10 A DAC cable or Fiber cable (with transceivers) connected to a Downlink port (in our example,
Port 26) on the first Quantum Maestro Orchestrator (1) and to the applicable port on the
Expansion Line Card on the Security Appliance 12.
11 A DAC cable or Fiber cable (with transceivers) connected to a Downlink port (in our example,
Port 26) on the second Quantum Maestro Orchestrator (2) and to the applicable port on the
Expansion Line Card on the Security Appliance 12.
12 A Security Appliance that is assigned to the Security Group 2 (14).
13 A Security Appliance that is assigned to the Security Group 2 (14).
14 All Security Appliances assigned to the Security Group 2.
