Check Point QUANTUM MAESTRO Manual page 93

Connecting cables between each Quantum Maestro Orchestrator and 2 out of 4 ports on the Quad Port
Card on each Security Appliance
Illustration
Legend
Item Description
A First Quantum Maestro Orchestrator.
B Second Quantum Maestro Orchestrator.
C Security Appliances in Security Groups.
A DAC cable connected to the dedicated Synchronization ports on the Quantum Maestro
Orchestrators.
Cables that connect odd ports on the Quad Port Card to the first Quantum Maestro
Orchestrator.
Cables that connect even ports on the Quad Port Card to the second Quantum Maestro
Orchestrator.
Connecting Two Quantum Maestro Orchestrators for Redundancy
Instructions
Important - In R80.20SP, this
connection method is supported only
with the
Accumulator
installed on Quantum Maestro
Orchestrators and Security Groups.
On each Security Appliance (C) in the Security
Group:
1. Connect a cable from
Port Card to a Downlink port on the first
Quantum Maestro Orchestrator (A).
2. Connect a cable from
Port Card to a Downlink port on the first
Quantum Maestro Orchestrator (A).
3. Connect a cable from
Port Card to a Downlink port on the
second Quantum Maestro Orchestrator
(B).
4. Connect a cable from
Port Card to a Downlink port on the
second Quantum Maestro Orchestrator
(B).
Quantum Maestro Getting Started Guide | 93
R80.20SP Jumbo Hotfix
(Take 105 and above)
Port 1 on the Quad
Port 3 on the Quad
Port 2 on the Quad
Port 4 on the Quad
