Explanations
Table: Explanations
Item Description
A port on the Layer 2 switch on the first site (3) that connects to a corresponding port (2) on
1
the Layer 2 switch on the second site (5).
A port on the Layer 2 switch on the second site (5) that connects to a corresponding port (1)
2
on the Layer 2 switch on the first site (3).
The Layer 2 switch on the first site.
3
4 Port on the Layer 2 switch on the first site that connects to the dedicated external
synchronization port (10) on the first Quantum Maestro Orchestrator (11) on the first site.
5 The Layer 2 switch on the second site.
6 Port on the Layer 2 switch on the second site that connects to the dedicated external
synchronization port (13) on the first Quantum Maestro Orchestrator (14) on the second
site.
Port on the Layer 2 switch on the first site that connects to the dedicated external
7
synchronization port (18) on the second Quantum Maestro Orchestrator (19) on the first
site.
8 Port on the Layer 2 switch on the second site that connects to the dedicated external
synchronization port (21) on the second Quantum Maestro Orchestrator (22) on the second
site.
9 DAC cables, Fiber cables (with transceivers), or Breakout cables that connect Downlink
ports on the first Quantum Maestro Orchestrator (11) on the first site to the Security
Appliance (25,
These cables connect to the odd port of an Expansion Line Card on Security Appliances.
10 The dedicated external synchronization port (Port 47) on the first Quantum Maestro
Orchestrator (11) on the first site.
This port connects with a DAC cable or Fiber cable (with transceivers) to the Layer 2 switch
(3 to port 4) on the first site.
11 The first Quantum Maestro Orchestrator on the first site.
12 DAC cables, Fiber cables (with transceivers), or Breakout cables that connect Downlink
ports on the first Quantum Maestro Orchestrator (14) on the second site to the Security
Appliance (26,
These cables connect to the odd port of an Expansion Line Card on Security Appliances.
The dedicated external synchronization port (Port 47) on the first Quantum Maestro
13
Orchestrator (14) on the second site.
This port connects with a DAC cable or Fiber cable (with transceivers) to the Layer 2 switch
(5 to port 6) on the first site.
14 The first Quantum Maestro Orchestrator on the second site.
27 and 30) on the first site.
29 and 31) on the second site.
Dual Site with two Switches
