Explanations:
Table: Explanations
Item
Description
1
Network 1 connected to ports on the Networking Device (3).
2
Network 2 connected to ports on the Networking Device (3).
3
Networking Device (router or switch) that connects your Network 1 and Network 2 to the
Quantum Maestro Orchestrators
4
Bond interface that connects Network 1 to the Quantum Maestro Orchestrators
This Bond interface provides a redundant Uplink connection for the traffic inspected by the
Security Appliances
5
Bond interface that connects Network 2 to the Quantum Maestro Orchestrators
This Bond interface provides a redundant Uplink connection for the traffic inspected by the
Security Appliances
6
SmartConsole Client that connects to the Management Server (7).
7
Management Server that manages Security Groups configured on the Quantum Maestro
Orchestrators
8
Layer 2 switch.
9
A Breakout cable connected to the Management port 1. See
Cables" on page 82
Note - You assign this Management port (or these split interfaces) to the applicable
Security Groups. Shared Management feature allows to assign the same
Management port (interface ethX-MgmtY) on a Quantum Maestro Orchestrator to
different Security Groups. The assigned Management port has a different IP
address and a different MAC address in each Security Group, to which this port is
assigned.
10
A DAC cable, Fiber cable (with transceivers), or Breakout cable that connects a first slave of
the first Bond (4) on the Networking Device (3) to the first Quantum Maestro Orchestrator (15).
11
A DAC cable, Fiber cable (with transceivers), or Breakout cable that connects a second slave
of the first Bond (4) on the Networking Device (3) to the second Quantum Maestro
Orchestrator (16).
12
A DAC cable, Fiber cable (with transceivers), or Breakout cable that connects a first slave of
the second Bond (5) on the Networking Device (3) to the first Quantum Maestro Orchestrator
(15).
13
A DAC cable, Fiber cable (with transceivers), or Breakout cable that connects a second slave
of the second Bond (5) on the Networking Device (3) to the second Quantum Maestro
Orchestrator (16).
(15
and 16) with Bond interfaces (Link Aggregation).
(29
and 30) in the applicable Security Group (31).
(26
and 27) in the applicable Security Group (28).
(15
and 16).
.
Connecting Two Quantum Maestro Orchestrators for Redundancy
"Splitting the Ports with Breakout
Quantum Maestro Getting Started Guide | 89
(15
and 16).
(15
and 16).
