Best Practice for Security Appliances 23000 series:
Install the expansion cards in this order:
1. Expansion Slot 3
2. Expansion Slot 4
3. Expansion Slot 5
4. Expansion Slot 1
5. Expansion Slot 2
Use Slots 1 and 2 only after all other slots are populated.
Overview of the expansion slots on the
LCD
Slot 1

Workflow

Table: Workflow
Step Device
1 On the
Networking
Device (3)
Connecting Two Quantum Maestro Orchestrators for Redundancy
front
Slot 4 Slot 5
Slot 2 Slot 3
Instructions
Perform these steps (refer to the device vendor documentation):
1. Configure a first Bond interface (4) on two slave ports.
This Bond interface connects Network 1 to the Quantum Maestro
Orchestrators.
Configure the applicable settings, so that the traffic from and to
Network 1 passes only on this Bond interface.
2. Configure a second Bond interface (5) on two slave ports.
This Bond interface connects Network 2 to the Quantum Maestro
Orchestrators.
Configure the applicable settings, so that the traffic from and to
Network 2 passes only on this Bond interface.
3. With a cable (10), connect the first slave interface of the first Bond
(4) interface to an Uplink port (in our example, Port 3) on the first
Quantum Maestro Orchestrator (15).
4. With a cable (11), connect the second slave interface of the first
Bond (4) interface to an Uplink port (in our example, Port 3) on the
second Quantum Maestro Orchestrator (16).
5. With cable (12), connect the first slave interface of the second Bond
interface (5) to an Uplink port (in our example, Port 9) on the first
Quantum Maestro Orchestrator (15).
6. With cable (13), connect the second slave interface of the second
Bond interface (5) to an Uplink port (in our example, Port 9) on the
second Quantum Maestro Orchestrator (16).
panel:
Storage
Devices
Appliance
Ports
