PSU pulled out:
Installing a Power Supply Unit
Important - Do not insert a PSU with a power cord connected to it.
Step Instructions
1 Make sure the mating connector of the new PSU is free of any dirt and obstacles.
2 Insert the PSU end into the opening.
3 Slide in the PSU until you feel a slight resistance.
4 Continue to press the PSU until it seats completely.
The PSU latch snaps into place. This confirms the proper installation.
5 Connect the power cord to the PSU connector.
6 Insert the other end of the power cord into an outlet of the correct voltage.
7 These should light up in green color:
1. The indicator on the PSU
2. The
page 36
If either the indicator, or the LED does not light up in green color, repeat the whole
procedure to remove the PSU and insert it again.
Power Supply Unit Status LED
)
Replacing Power Supply Units
(see "Power Supply Unit Status LEDs" on
