Mycom S CLM 153
"
Endress+Hauser
3
Installation
3.1
Incoming acceptance, transport, storage
• Make sure the packaging is undamaged!
Inform the deliverer about damage to the packaging.
Keep the damaged packaging until the matter has been clarified.
• Make sure the contents are undamaged!
Inform the deliverer about damage to the delivery contents.
Keep the damaged products until the matter has been clarified.
• Use the delivery papers and your order to check that the scope of delivery is
complete.
• For storage and transport purposes, pack the instrument so that it is protected against
impacts and humidity. The original packaging offers the best protection. Also, keep to
the approved ambient conditions (see "Technical data").
• If you have any questions, please contact your supplier or your nearest
Endress+Hauser sales centre, (see the back page of these Operating Instructions).
3.2
Installation conditions
3.2.1
Dimensions
You can find the dimensions and lengths of the transmitter in the Technical data on
page 101 ff.
3.3
Installation
3.3.1
Installation instructions
• The standard use of the Mycom S CLM 153 transmitter is as a field instrument.
• The Mycom S CLM 153 transmitter can be fixed to vertical or horizontal pipes using
the round post fixture available from Endress+Hauser (see Accessories). When
installing the instrument outdoors, you also require the weather protection cover
CYY 101. This cover is compatible with all field instrument installations options.
• Always install the transmitter so that the cable entries point downwards.
• The transmitter can be installed as a panel-mounted unit as well.
3.3.2
Wall mounting
Caution!
• Check that the temperature does not exceed the maximum permitted ambient
temperature (–20° ... +60°C). Install the instrument in a shady location. Avoid direct
sunlight.
• Mount the wall mounting housing so that the cable entries always point downwards.
3 Installation
9
