6 Commissioning
CODE
T6
T7
T8
T9
T10
26
DISPLAY
Hold
Channel 1
Meas.principle Cd
Unit auto
Hold
Channel 1
0.1cm-1
Cell const.
Cable resist. 0Ohm
Hold
Channel 2
Meas.principle Cd
Unit auto
Hold
Channel 2
Cell const. 0.1cm-1
Cable resist. 0Ohm
Hold
CHOICE INFO
(default = bold)
Mode: Cond. Select the operating mode measuring
Unit/ auto circuit 1
medium (not for related circuits)
If the operating mode changes, the user
settings are automatically reset.
Operating mode: Cond. (conductivity,
difference calculation), resistance,
concentration
Unit (with cond. / resistance operating mode,
difference calculation): auto, mS/cm, µS/cm /
auto, k Ω , M Ω .
Unit (with concentration operating mode,
difference calculation): ppm, mg/l, %, TDS.
The optimum unit is automatically selected
with "auto".
Medium (with "concentration" operating
mode): NaOH, HNO3, H3PO4, H2SO4, Table
1 to 4
Rel. unit (with ratio calculation): Unit of the
characteristic value defined in the previous
field. Options: none, %
inductive: Select measuring circuit 1
Cell const.: 1.98cm-1 Cell constant: The exact cell constant is
Install.factor provided in the sensor quality certificate.
Cable resistance (for conductive): Enter the
conductive: cable resistance.
Cell const.: 0.1cm-1 Installation factor (for inductive): Enter the
0 Ω
Cable installation factor here.
resist.
Mode: Cond. Select the operating mode for measuring
Unit/ auto
circuit 2
medium (not for related circuits; only two circuit)
If the operating mode changes, the user
settings are automatically reset.
Operating mode: Cond. (conductivity),
resistance, concentration
Unit (with cond. / resistance operating mode):
auto, mS/cm, µS/cm / auto, k Ω , M Ω .
Unit (with concentration operating mode):
ppm, mg/l, %, TDS.
The optimum unit is automatically selected
with "auto".
Medium (with "concentration" operating
mode): NaOH, HNO3, H3PO4, H2SO4, Table
1 to 4
inductive: Select measuring circuit 2
Cell const.: 1.98cm-1 (only two circuit)
Install.factor Cell constant: The exact cell constant is
provided in the sensor quality certificate.
conductive: Cable resistance (for conductive): Enter the
Cell const.: 0.1cm-1 cable resistance.
0 Ω
Cable Installation factor (for inductive): Enter the
resist. installation factor here.
°C Select temperature unit
°F °C: Degrees Celsius
°F: Degrees Fahrenheit
