Endress+Hauser Mycom S CLM 153 Operating Instructions Manual page 13

Mycom S CLM 153
#
!
135042-0002-4B
Stromausgang / current out / Hart
inductive
83 16 15 84 12 13 11 S
Kanal / channel 1
83
Koax / coax
rot / red
16
15
weiß / white
Koax / coax
84
11 grün / green
12 ( gelb / yellow )
13
weiß / white
NTC / Pt100 / Pt1000
Endress+Hauser
Warning!
A mains disconnecting device must be installed near the instrument and must be
identified as the mains disconnection device for the Mycom S CLM 153
(see EN 61010-1).
Note!
• Connect unused signal wires from input and output lines to the internal PE rail of the
CLM 153.
• The current/resistance input may only be connected using a screened cable, whereby
the screen at the transmitter must be applied to the PE rail.
4.1.2 Connection compartment label
CLM153
zusammengehörige
Klemmen /
combined clamps
conductive
83 16 15 84 12 13 11 S
Kanal / channel 2
83
16
Koax / coax
15
schwarz / black
84
11 grün / green
12 ( gelb / yellow )
13
weiß / white
NTC / Pt100 / Pt1000
Fig. 7: Connection compartment label (in the connection compartment of the transmitter)
EX
F
F L N
Kontakte, Best.-Variante /
-..1.. -..2.. -..3..
+
51 54 44 51 54 21
52 55 45 52 55 22 52 55
-
4 Wiring
non EX
contacts, order code.
-..4.. -..5..
+ + +
51 54 21 51 23 21 51 23 21
22 52 24 22 52 24
- - -
+ +
22
- -
13
