Controller output
Relay contacts
Galvanic isolation
Electrical
connection
Measured value resolution
1
Measured error display
1
Measured error current
output
1
Repeatability
Endress+Hauser
Function (selectable):
Switch behaviour
Control gain K
R
Integral action time T
n
Derivative action time T
v
With the maximum settable frequency in PFM
With the maximum settable period length in PWM
With PWM minimum switch-on period
The NC/NO contact type can be set by software.
Switching voltage
Switching current
Switching power
Lifespan
At the same potential are:
• Current output 1 and power supply
• Current output 2 and resistance input.
The remaining circuits are galvanically isolated from each other.
Power supply for CLM 153-xxxx0xxxx
Frequency
Power supply for CLM 153-xxxx8xxxx
Power consumption
Separation voltage between galvanically isolated
circuits
Terminals, max. cable cross-sectional area
10.3

Performance characteristics

Conductivity:
Temperature:
Conductivity, resistance, concentration:
Temperature:
additionally max. 0.2% of current range maximum
Conductivity, resistance, concentration:
Temperature:
1
: acc. to IEC 746-1, under nominal operating conditions
10 Technical data
Pulse-length controller (PWM)
Pulse-frequency controller (PFM)
Three-point step controller (3-PS)
Analogue (via current output)
P / PI / PID
0.01 ... 20.00
0.0 ... 999.9 min
0.0 ... 999.9 min
-1
120 min
1 ... 999.9 s
0.4 s
max. 250 V AC / 125 V DC
max. 3 A
max. 750 VA
≥ 5 million switching cycles
100 ... 230 V AC +10/–15%
47 ... 64 Hz
24 V AC/DC +20/–15%
max. 10 VA
276 V
rms
3 x 2.5 mm²
0.001 µS/cm
0.1 K
±0.5% ±2 digits of measured value
< 0.5 K
±0.2% ±2 digits of measured value
max. 0.1% of measuring range
