Mycom S CLM 153
Service adapter
Optoscope
ChemoClean cleaning
Sensor measuring cable
Measuring cable as yard
goods
Flat seal
Endress+Hauser
Type
InduMax P Very chemically stable sensor thanks to PFA jacketing.
CLS 50 PEEK version for high temperatures to 180 °C. With
approval. Overall cable length to 55 m.
Technical Information:
TI 182C/07/en, Order No.: 50090385
InduMax H Sensor shaft made of highly resistant, plastic (PEEK)
CLS 52 which can be used with foodstuffs. Very short
temperature response times (t
range from 10 µS/cm to 2000 mS/cm.
Technical Information:
TI 167C/07/en, Order No.: 50086110
The service adapter aids communication between Endress+Hauser transmitters and
the PC using the service interface. You can use it to load new firmware and to save/write
customer data (using a PC with the Windows 95/98 or Windows NT operating system).
Sensor cleaning can be automated with the injector CYR 10 and the appropriate
accessories for the different assemblies.
• Sensor measuring cable CPK 9 with TOP68 plug-in head (for high temperature
applications, IP 68 / NEMA 6X, also for Ex). Extension with cable CYK 71 possible, see
table "Measuring cable as yard goods".
• Measuring cable CLK 5 for inductive sensors
• Measuring cable CYK 71 for conductive sensors
• Junction box VBM: Junction box for extending measuring cable connection between
sensor and transmitter. Two threaded joints for e.g. combination sensor.
Material: aluminium casting, ingress protection IP 65. Order No. 50003987
Cable
Measuring cable for conductive conductivity sensors, consisting
of a coaxial cable and 4 pilot wires
CYK 71
Measuring cable for Ex applications
Extension measuring cable for inductive conductivity sensors
CLK 5
CLS 50 and CLS 52. To be used with the connection box VBM.
Flat seal for sealing the front panel mounting of the CLM 153. Order No.: 50064975
Properties
< 5s). Measuring
90
Description
9 Accessories
Applications
0
• Chemical industry:
• Concentration measurement
of acids and alkalis
• Product monitoring
• Phase separation of product/
product mixtures
• Foodstuff industry
• Control of CIP systems
Order number
50085333
50085673
50085473
