Mycom S CLM 153
CODE
T11
T12
T13
T14
T15
T16
Endress+Hauser
DISPLAY
Hold
Hold
Temp.sensor K1
Pt100
Pt1000
NTC30
Hold
Compensation CH1
Temp.comp.
linear
Alpha value
02.10%/K
Actual temp.
025.0°C
Offset
0.0°C
Hold
Hold
Temp.sensor K2
Pt100
Pt1000
NTC30
Hold
Compensation K2
K1
Temp.value
Temp.comp.
linear
Alpha value
02.10%/K
Actual temp.
025.0°C
Offset
0.0°C
CHOICE
INFO
(default = bold)
ATC CH1
Select temperature compensation channel
ATC CH2
1/2
MTC
ATC: Automatic temperature compensation
MTC+Temp
via temperature sensor
MTC: Temperature compensation via manual
value entry
MTC+Temp: Temperature compensation via
manual temperature entry. The displayed
temperature, however, is measured by the
temperature sensor.
Pt 100
Select temperature sensor channel1
Pt 1000
NTC 30k
Temp.comp
linear
Temperature compensation input 1
Alpha
2.1%/K
Temp. value: Automatic temperature
value:
25.0°C
compensation with a temp. sensor input 1 or
Actual
0.0°C
input 2
temp.:
Temp. comp.: Selection of the temperature
Offset:
compensation – none, linear, NaCl, Table 1 to
4
Alpha value: Entry of the conductivity
coefficient α .
Actual temp.: The measured temperature is
displayed.
Offset: Temperature difference between
measured and output temperature
(–10 ... +10 °C).
ATC CH1
Select temperature compensation
ATC CH2
channel 2
MTC
(only two circuit)
MTC+Temp
Pt 100
Select temperature sensor input 2
Pt 1000
(only two circuit)
NTC 30k
Temp.value
Input 1
Temperature compensation input 2
Temp.comp
none
(only two circuit)
.:
2.1%/K
Temp. value: Automatic temperature
Alpha
25.0°C
compensation with a temp. sensor input 1 or
value:
0.0°C
input 2
Actual
Temp. comp.: Selection of the temperature
temp.:
compensation – none, linear, NaCl, Table 1 to
Offset:
4
Alpha value: Entry of the conductivity
coefficient α .
Actual temp.: The measured temperature is
displayed.
Offset: Temperature difference between
measured and output temperature
(–10 ... +10 °C).
6 Commissioning
27
