Mycom S CLM 153
Endress+Hauser
CODE CHOICE
(default = bold)
A3 Mode:
Unit
Medium
Comb. unit
A4 Measuring circuit 1
Measuring circuit 2
Measuring channel 1 (or 2):
AA1 Mode:
Unit/
medium
AA2 Cell
const.:
Cable
resist.
Adaption
factor
AA3 Measured
value:
Temperatur
e:
INFO
Cd. Select operating mode
auto (only related circuits)
If the operating mode changes, the user settings are
% automatically reset. The settings you make here apply to
both measuring circuits.
Mode: Cd. (conductivity, difference calculation), resistance,
concentration
Unit (with Cond. operating mode, difference calculation):
auto, µS/cm, mS/cm, S/cm, µS/m, mS/m, S/m
Unit (with resistance operating mode, difference calculation):
auto, k Ω• cm, M Ω• cm, k Ω• m, M Ω• m.
Unit (with concentration operating mode, difference
calculation): ppm, mg/l, %, TDS.
The optimum unit is automatically selected with "auto".
Medium (with "concentration" operating mode): NaOH,
HNO3, H3PO4, H2SO4, Table 1 to 4
Rel. unit (ratio calculation): Unit of the characteristic value
defined in the previous field. Options: none, %
Select measuring circuit
Cond. Select operating mode
auto (not for related circuits)
If the operating mode changes, the user settings are
automatically reset.
Operating mode: Cond. (conductivity), resistance,
concentration
Unit (with cond. / resistance operating mode): auto, mS/cm,
µS/cm / auto, k Ω , M Ω .
Unit (with concentration operating mode): ppm, mg/l, %,
TDS.
The optimum unit is automatically selected with "auto".
Medium (with "concentration" operating mode): NaOH,
HNO3, H3PO4, H2SO4, Table 1 to 4
00.000cm- Select measuring channel 1 or 2
1 Cell constant: The exact cell constant is provided in the
00.00 Ω
sensor quality certificate.
Cable resistance (for conductive): Enter the cable
resistance.
Adaption factor (for inductive): Enter the adaption factor
here.
01 s Set measured value attenuation
The mean value over the set time is displayed.
01 s
(01 ... 30 s)
6 Commissioning
