6 Commissioning
76
CODE CHOICE
(default = bold)
Instrument check:
YC1 Display
Keypad
RAM
EEPROM
Flash
DAT handling:
YD1 Save to DAT
Read from DAT
Erase DAT
Save to DAT:
YD2 !!Caution!! All the data on
the DAT module will be
deleted.
Read from DAT:
YD3 in process
Erase DAT:
YD4 !!Caution!! All the data on
the DAT module will be
deleted.
Reset
YE1
INFO
Selection for check
Display: All the fields are queried alternately. Defective
cells become visible.
Keypad: All the keys must be pressed one after the
other. If the system is functioning perfectly, the
appropriate symbols appear in the display.
RAM: "RAM O.K" message if there are no errors.
EEPROM: "EEPROM O.K" message if there are no
errors.
Flash (memory): "Flash OK" message if there are no
!
errors.
Note!
Leave this item by pressing "PARAM".
DAT selection
Save to DAT: You can save the both the configuration
and the logbooks of your transmitter to the DAT mod-
ule.
Read from DAT: Copy the configuration saved on the
DAT module into the EEPROM of the transmitter.
!
Delete DAT: Delete all data on the DAT module.
Note!
• After the "Read from DAT" copying procedure, a reset
is triggered automatically, and the device is config-
ured with the copied values. (See below for reset).
• If there is no DAT module inserted, a
message appears on the display.
Note in display
For safety reasons, you are asked if you really want to
overwrite the existing data.
Data were written to the DAT module
Note in display
For safety reasons, you are asked if you really want to
overwrite the existing data.
Reset
You can restart the Mycom S with this function (similar
to the "warm start" on your computer). You can use this
!
function if the Mycom S does not react as expected.
Note!
This reset does not change saved data.
