6 Commissioning
40
CODE CHOICE
(default = bold)
Create alpha table:
GB1 Table 1
Table 2
Table 3
Table 4
GBB2 01
(1 ... 10)
GBB3 °C
000.0
GBB4 OK
Delete element(s)
GBB5 °C
020.0 °C
025.0 °C
GBB6 Valid table
Reference temperature:
GBC1 For laboratory
measurement:
25.0 °C
(-35 ... +250 °C)
INFO
Select table
Select a table to edit.
Entry of the number of support points (value pairs)
Value pair: Temperature and conductivity coefficient α .
%/K Entry of the value pairs
00.00 Enter temperature and conductivity coefficient,
(number of value pairs required = number of support
points desired in Field GBB2).
Selection:
Are the value pairs OK or do you want to delete
elements?
%/K Delete:
02.00 Select the rows to be deleted, delete them with
04.00 confirm this with "E".
Note in display:
The table is active after confirmation by pressing "E".
Cancel by pressing "PARAM".
Entry of the reference temperature
to which the medium temperature should be
compensated. Here, enter the temperature at which the
α value was determined, (you can take this from the
data sheets from which you also took the α value).
