Mycom S CLM 153
"
Endress+Hauser
Fig. 4:
Panel mounting
and post mounting for CLM 153, horizontal
Caution!
Danger of device failure. For outdoor use, the weather protection cover CYY 101 is
required, (see fig. 5 and Accessories).
Fig. 5:
Post mounting for the transmitter CLM 153 with weather protection cover CYY 101.
3.4
Post-installation check
After installing the transmitter, carry out the following checks:
Instrument status and specifications
Is the transmitter undamaged?
Installation
Are the measuring point number and the labelling correct?
Process environment/conditions
Is the transmitter protected against rainfall and direct
sunlight?
3 Installation
and vertical
Note
Visual inspection
Note
Visual inspection
Note
For outdoor installation, the weather
protection cover CYY 101 is required
(see Accessories).
11
