9 Accessories

Offline configuration
DAT module
Assemblies
Conductivity sensors
98
9 Accessories
The PC tool provides you with a tool for configuring your measuring point at the PC using
a simple and self-explanatory menu structure. Write the configuration to the DAT module
using the RS232 interface on the PC. The module can then be plugged into the
transmitter. You can switch the language via software. The offline configuration system
consists of a DAT module, the DAT interface (RS 232) and the software for use with
Windows NT/95/98/2000. Order No.: 51507133
The DAT module is a memory device (EEPROM) which can be easily plugged into the
connection compartment of the transmitter. Using the DAT module you can
• save the complete settings, the logbooks and the data logger of a transmitter and
• copy the complete settings to other CLM 153 transmitters with identical hardware
functionality.
This considerably reduces the effort to install or service several measuring points.
Order No.: 51507175
Type
DipFit W Immersion and installation assembly with flange
CLA 111 DN 100. The Chemoclean sensor cleaning system can
be integrated without any conversion needed.
Technical Information:
TI 135C/07/en, Order No.: 50076858
DipFit W Immersion assembly with thread G 1, G ¾ or NPT ¾".
CYA 611 Technical Information:
TI 166C/07/en, Order No.: 50085985
DipFit P Immersion assembly with flange DN 80 PN 16, ANSI 3"
CLA 140 150 lbs or JIS 10K 80A. Sensor holder in bayonet style.
Technical Information:
TI 1196C/07/en, Order No.: 51500081
Type
ConduMax W Can be adapted to the process for optimum results
CLS 12/13 thanks to different designs. Installation in pipe or flow
vessel at temperatures to 250 °C and pressures to
40 bar. Sensor shaft made of die-cast aluminium,
sensors of stainless steel 1.4571 (AISI 316 Ti).
Technical Information:
TI 082C/07/en, Order No.: 50059349
ConduMax W Sterilisable up to 150°C Polished shaft made of
CLS 15 stainless steel 1.4435 (AISI 316L). High accuracy
thanks to individually measured cell constant.
Installation in pipe or flow vessel.
Technical Information:
TI 109C/07/en, Order No.: 50065950
ConduMax H Pure and ultrapure water sensor: Measuring range
CLS 16 from 0.04 to 500 µS/cm. Water-proof connection
TOP68 or fixed cable. Sterilisable up to 150°C EHEDG
and 3A certificates.
Technical Information:
TI 227C/07/en, Order No.: 51503431
ConduMax W High chemical, thermal and mechanical stability.
CLS 21 Sensor shaft in PES (polyethersulphon).
Technical Information:
TI 085C/07/en, Order No.: 50059352
Properties
Properties
Mycom S CLM 153
Applications
• Water
• Wastewater
• Process industry
• Water
• Wastewater
• Wastewater, paper industry
Applications
• Industry
• Power plants (e.g.
condensate measurement)
• Low conductivities at high
pressures and high
temperatures
• Monitoring ion exchangers
• Reverse osmosis
• WFI ( Water for Injection)
• Chip cleaning
• Pure water
• Ultrapure water
• Electro-deionisation
• Distillation
• WFI ( Water for Injection)
• Monitoring low concentrated
saline solutions
• Potable water treatment
• Wastewater treatment
