Mycom S CLM 153
Endress+Hauser
2
Identification
2.1
Device designation
2.1.1
Product structure
Conductivity transmitter in aluminium housing for wall mounting with one alarm and two
output contacts for NAMUR, ChemoClean and controller functions as well as three
binary inputs, logbooks, data loggers, USP limit functions. Plain text operation.
247x167x111 mm (HxWxD). Degree of protection IP 65.
Certificates
A
Basic equipment: non-Ex
G
With Atex approval, Atex II (1) 2G EEx em ib[ia] IIC T4
O
With FM approval; NI Cl. I, Div. 2, Sensor IS Cl. I, Div. 1
P
With FM approval; NI Cl. I, Div. 2
S
With CSA approval; NI Cl. I, Div. 2, Sensor IS Cl. I, Div. 1
T
With TIIS approval
Measuring input
1
1 measuring circuit for conductive sensors, conductivity/resistance and temperature
2
1 measuring circuit for inductive sensors, conductivity/resistance and temperature
3
2 measuring circuits for conductive sensors, conductivity/resistance and temperature
4
2 measuring circuits for inductive sensors, conductivity/resistance and temperature
Measuring output
A
2 current outputs 0/4 ... 20 mA, passive (Ex and non-Ex)
B
2 current outputs 0/4 ... 20 mA, active (non-Ex)
C
HART with 2 current outputs 0/4 ... 20 mA, passive (Ex and non-Ex)
D
HART with 2 current outputs 0/4 ... 20 mA, active (non-Ex)
E
PROFIBUS-PA, without current outputs
Contacts, current input
0
Without additional contacts
1
3 additional contacts
2
2 additional contacts, 1 passive current input (Ex and non-Ex)
3
2 additional contacts, 1 resistance input (non-Ex)
4
1 additional contact, 2 passive current inputs (Ex and non-Ex)
5
1 additional contact, 1 passive current input, 1 active resistance input (non-Ex)
Power supply
0
8
CLM 153-
100 ... 230 V AC
24 V AC / DC
Language versions
A
E / D
B
E / F
C
E / I
D
E / ES
E
E / NL
F
E / J
Cable connection
0
Cable glands M 20 x 1.5
1
Adapter for cable gland NPT ½"
2
Adapter for cable gland G ½
Additional equipment
0
Without additional equipment
1
Additional equipment: DAT module
Configuration
0
Factory settings
Complete order code
2 Identification
7
