UM1855
1

Overview

1.1

Features

•
STM32L476ZGT6 microcontroller with 1-Mbyte Flash memory and 128-Kbyte RAM
•
four power supply options: power jack, ST-LINK/V2-1 USB connector, USB OTG FS
connector, daughterboard
•
microcontroller supply voltage: 3.3 V or range from 1.71 V to 3.6 V
•
two MEMS digital microphones
•
two stereo audio headphones jack outputs with independent audio content
•
slot for microSD card supporting SD, SDHC, SDXC
•
4-Gbyte microSD card bundled
• 16-Mbit (1M x 16 bit) SRAM device
• 128-Mbit (8M x 16 bit) NOR Flash memory device
•
256-Mbit Quad-SPI Flash memory device with double transfer rate (DTR) support
•
RF-EEPROM with I²C bus
•
EEPROM supporting 1 MHz I²C-bus communication speed
•
RS-232 port configurable for communication or MCU flashing
•
IrDA transceiver
•
USB OTG FS Micro-AB port
• CAN 2.0A/B-compliant port
• joystick with four-way controller and selector
• reset and wake-up / tamper buttons
•
touch-sensing button
•
light-dependent resistor (LDR)
•
potentiometer
•
coin battery cell for power backup
•
LCD glass module daughterboard (MB979) with 40x8-segment LCD driven directly by
STM32L476ZGT6
•
2.8-inch 320x240 dot-matrix color TFT LCD panel with resistive touchscreen
•
smartcard connector and SWP support
•
NFC transceiver connector
• connector for ADC input and DAC output
• power-metering demonstration with dual-channel sigma-delta modulator
•
PT100 thermal sensor with dual-channel sigma-delta modulator
•
MCU current consumption measurement circuit
•
access to comparator and operational amplifier of STM32L476ZGT6
•
extension connector for motor control module
•
JTAG/SWD, ETM trace debug support, user interface through USB virtual COM port,
embedded ST-LINK/V2-1 debug and flashing facility
•
extension connector for daughterboard
