ST STM32L476G-EVAL User Manual page 35

UM1855
Table 14. LCD-daughterboard-related configuration elements (continued)
LCD
Element
segment
R48
SEG11
SB8
R39
SEG12
SB3
R38
SEG13
SB6
R97
SEG18
SB34
R98
SEG19
SB36
R99
SEG20
SB42
R65
SEG22
SB17
R64
SEG23
SB16
R36
SEG24 SB2
SB27
R33
SEG25 SB4
SB30
SEG26 SB28
SEG27 SB29
R103
SEG38
SB26
SEG39 R104
The custom LCD glass module used on MB979 daughterboard is XHO5002B. To optimize
the number of driving signals, the display elements are connected to eight common planes
called COMx (LCDCOMx in the schematic digrams), where "x" can be substituted with
figures from "0" to "7". The other pole of each display element is called segment, SEGy
(LCDSEGy in the schematic diagrams), where "y" can be substituted with figures from "0" to
"39". Each combination of COMx and SEGy addresses one display element.
Table 16, Table 17
rows, SEGy in columns. The table cells then display the display element names
All manuals and user guides at all-guides.com
Setting to enable
LCD glass
module
In PB11 routed to LCDSEG11
Open PB11 not routed to Quad-SPI Flash memory device
In PB12 routed to LCDSEG12
Open PB12 not routed to Quad-SPI Flash memory device
In PB13 routed to LCDSEG13
Open PB13 not routed to Touch sensing
In PC0 routed to LCDSEG18
Open PC0 not routed to motor control
In PC1 routed to LCDSEG19
Open PC1 not routed to motor control
In PC2 routed to LCDSEG20
Open PC2 not routed to motor control
In PC4 routed to LCDSEG22
Open PC4 not routed to motor control
In PC5 routed to LCDSEG23
Open PC5 not routed to motor control
In PC6 routed to LCDSEG24
Open PC6 not routed to Touch sensing
Open PC6 not routed to for motor control
In PC7 routed to LCDSEG25
Open PC7 not routed to Touch sensing
Open PC7 not routed to for motor control
Open PC8 not routed to motor control
Open PC9 not routed to motor control
In PE2 routed to LCDSEG38
Open PE2 not routed to Trace
In PE3 routed to LCDSEG39
and Table 22 show the LCD element mapping. COMx are ordered in
DocID027351 Rev 3
Hardware layout and configuration
Description
Table 15,
35/100
