Table 30 shows the assignment of signals to CN13 connector.
The serial communication with the module plugged in CN13 can either use SPI
communication protocol (default) or UART communication protocol.
CN13
NFC line name
terminal
NFC_IRQOUTN or
1
NFC_IRQINN or
2
3
4
5
6
7
8
2.29

Dual-channel sigma-delta modulators STPMS2L

2.29.1

STPMS2L presentation

With its DFSDM interface, the STM32L476ZGT6 microcontroller can directly interact with
sigma-delta modulator devices, such as STPMS2L.
STPMS2L comprises two analog measuring channels based on second-order sigma-delta
modulators. Typically, it can be used in power metering where both voltage and current
need to be known. One channel measures the voltage, the other channel measures the
current.
DAT port outputs converted measurement data on the DFSDM_DATIN1 line, received by
the STM32L476ZGT6 DFSDM controller. The data from STPMS2L are synchronized with
DFSDM_CKOUT clock generated by the STM32L476ZGT6 DFSDM controller and received
on CLK terminal of STPMS2L.
There are two STPMS2L devices on STM32L476G-EVAL, sharing the DFSDM clock. One is
wired such as to support a power-metering demonstrator. The other allows measuring
temperature using the PT100 sensor.
All manuals and user guides at all-guides.com

Table 30. CN13 NFC connector terminal assignment

MCU port
PB7
UART_TX
PB6
UART_RX
NFC_NSS PF11
NFC_MISO PB14
NFC_MOSI PB15
NFC_SCK PB13
+3V3 -
GND -
DocID027351 Rev 3
Hardware layout and configuration
Function
Interrupt output for NFC device
Connected to STM32L476ZGT6 UART RX
Interrupt input for NFC device
Connected to STM32L476ZGT6 UART TX
SPI slave select
SPI data, slave output
SPI data, slave input
SPI serial clock
Main power supply/power supply for RF drivers
Ground
