UM1855
2.4

Clock references

Two clock references are available on STM32L476G-EVAL for the STM32L476ZGT6 target
microcontroller:
•
32.768 kHz crystal X1, for embedded RTC
•
8 MHz crystal X2, for main clock generator
The main clock can also be generated using an internal RC oscillator. The X2 crystal is in a
socket. It can be removed when the internal RC oscillator is used.
Solder
bridge
SB41
SB33
Solder
bridge
SB24
SB23
2.5

Reset sources

Reset signal of the STM32L476G-EVAL board is active low.
All manuals and user guides at all-guides.com

Table 3. X1-crystal-related solder bridge settings

Setting
Default setting.
Open PC14-OSC32_IN terminal is not routed to extension connector CN7. X1 is
used as clock reference.
PC14-OSC32_IN is routed to extension connector CN7.
Closed R87 must be removed, for X1 quartz circuit not to disturb clock reference
or source on daughterboard.
Default setting.
Open PC15-OSC32_OUT terminal is not routed to extension connector CN7.
X1 is used as clock reference.
PC15-OSC32_OUT is routed to extension connector CN7.
Closed R88 must be removed, for X1 quartz circuit not to disturb clock reference
on daughterboard.

Table 4. X2-crystal-related solder bridge settings

Setting
Default setting.
Open PH0-OSC_IN terminal is not routed to extension connector CN7. X2 is
used as clock reference.
PH0-OSC_IN is routed to extension connector CN7.
Closed X2 and C54 must be removed, in order not to disturb clock reference or
source on daughterboard.
Default setting.
Open PH1-OSC_OUT terminal is not routed to extension connector CN7. X2 is
used as clock reference.
PH1-OSC_OUT is routed to extension connector CN7.
Closed R95 must be removed, in order not to disturb clock reference or source on
daughterboard.
DocID027351 Rev 3
Hardware layout and configuration
Description
Configuration
19/100
99
