The data that is displayed in the table always matches the data in the graph. Use the
Data Map (see page 57) the change the displayed data.
3.5.5.

Meter display

Tap Meter to switch to meter view
1.

Meter options

You can use the meter mode to view data without collecting it or to display data while
it is being collected.
If you switch to meter mode without running TriLink (i.e. without taping Run
TriLink continuously takes measurements from all active sensors, MultiLab displays it
but the data is not stored. A small camera icon
left of the screen.
You can display one meter at a time. To select what sensor to display pick it from the
sensors pick list located above the meter
To collect and store data while viewing it in Meter display, simply tap Run
small running man icon
2.

Meter types

There are three meter types: Analog
To select a meter type, tap the corresponding icon on the meter toolbar below the
meter
will be displayed on the bottom left of the screen.
, Digital
Chapter 3 Working with Pocket PC
will be displayed on the bottom
and Bar .
),
. A
63
