To view annotations:
Click Graph on the menu bar, then select Show annotation (this option is usually
selected by default)
To add an annotation:
1. Place a cursor on the desired point
2. Click Add new annotation
new annotation caption edit box
3. Type in the text, then click OK
To move an annotation:
1. Click Move annotation
2. Click on the annotation you want to move, then drag it to the new
position
3. Click Move annotation
annotation mode
To edit an annotation:
1. Place a cursor at the point where the annotation is connected
2. Click Graph on the menu bar, then click Edit annotation
3. Edit your annotation, then click OK
To delete an annotation:
1. Place a cursor at the point where the annotation is connected
2. Click Graph on the menu bar, then click Delete annotation
To hide all annotations:
Click Graph on the menu bar, then click Show annotation to
uncheck it

9.Add a graph to the project

MultiLab displays new data in the graph window every time you start a new
recording. You can always display previous data using the Edit graph dialog box or
by double-clicking on the data's icon in the Data Map. If you want to save a graph
on the graph toolbar to display the
on the graph toolbar
a second time to exit the move
Chapter 4 Working with a desktop computer 93
