2.5. View the Data

2.5.1.

Display Options

MultiLab features four views. Three views to display data: Graph view, Table view
and Meter view. The fourth view, the Data Map enables you to navigate through the
available data sets.
To switch to a certain view tap the corresponding tool on the main tool bar:

– Data Map

– Graph view

– Table view
– Meter view
2.5.2. Data Map
The Data Map displays the list of data sets that were recorded or downloaded in the
current session, as well as the lists of all the processed data sets
The items in the Data Map are sorted into three main categories:
•
Experiments
•
Processed data
To display the complete list of sensors for any individual experiment, tap the plus
sign (+) next to it.
To collapse a list under an individual experiment, tap the minus sign (-) next to it.
To display a certain data set tap its name on the list, then tap Show
To hide a data set tap its name on the list, then tap Hide
Showing or hiding a data set with the Data Map applies both to the Graph and Table
views.
2.5.3. Graph view
Tap Graph to display the graph. The default graph display is the data set or
sets plotted vs. time, but you can change the X-axis to represent any of the individual
data sets (see page 34).
