5. Tap OK
5. Select display
Tap a display on the main toolbar:
Graph , Table
Note: If you begin collecting data from the opening screen MultiLab
prompts to graph view
6. Start collecting data
Tap Run on the main toolbar.
If the recording rate is 25 measurements per second or less, MultiLab displays the
data in real time, plotting it on the graph as it is being recorded. If the recording rate
is higher than 25/s, the data will be downloaded and displayed automatically, once
the data recording is finished.
You can stop recording anytime by taping Stop
3.4.2.

Download Data

Whenever data is received from the TriLink, it is accumulated and displayed
automatically by MultiLab. There are two modes of communication: Online and Post-
Experiment.
Online communication
When TriLink is connected to the Pocket PC and programmed to run at sampling
rates of up to 25/s, TriLink transmits each data sample immediately, as it is recorded,
to the Pocket PC. The software thus displays the data in real-time in both the graph
and table window.
When TriLink is connected to the Pocket PC and programmed to run at a sampling
rate of 50/s or higher, data is accumulated in TriLink's internal memory. This data is
not transmitted to the Pocket PC until the recording period has ended, when the data
is automatically downloaded to the Pocket PC and displayed.
or Meter
Chapter 3 Working with Pocket PC
on the main toolbar.
