Print; Print A Graph; Print A Table - Fourier TriLink User Manual

7. On the File menu, click Save As
8. In the File name box, type a name for the workbook
9. In the Save as type list, click the CSV format
10.
To import files that were previously exported from MultiLab open MultiLab and import
the file as described above as they are already in CSV format.
4.4.9.

Print

1.Print a graph

1. Click Print
2. Select the Graph 1 option (when in split graph mode you can choose
between Graph 1 and Graph 2)
3. Click Print to open the print dialog box
4. Click OK
MultiLab will print exactly what you see in the graph display.

2. Print a table

1. Click Print
2. Select the Table option
3. If you want to print only a specific range, uncheck the Print all data
check box and type the desired row numbers into the To and From
edit boxes
4. Click Print to open the print dialog box
5. Click OK
Click Save
on the main toolbar
on the main toolbar
Chapter 4 Working with a desktop computer 87
