4.6.2.

Start Recording

Click Run on the main toolbar. Click the down arrow to change the
recording mode.
4.6.3.

Stop Recording

Click Stop on the main toolbar
4.6.4.

Clear TriLink's Memory

To erase all experiment data currently stored in the TriLink, click Clear memory in
the Logger menu (TriLink must first be connected to the PC).
4.6.5.

Select TriLink's operating mode

To enable TriLink's Auto ID mode (see on page 14):
1. Connect TriLink to the PC
2. Click Logger on the menu button, then click Auto ID
To switch to 8 sensors click Logger on the menu bar then click Auto ID a second
time to uncheck the Auto ID option.
4.6.6.

Calibrating the sensors

MultiLab enables you to calibrate any of the linear sensors manually. This two point
calibration method sets both the gain (slope) and offset (intercept) of the sensor's
conversion function. The calibration procedure affects MultiLab readings only.
1. Select the Calibrate sensors option from the Logger menu
2. Choose a sensor from the Select sensor drop list and click OK
3. Click on the Calibration tab
4. Enter a distinct real value in each of the Real Value edit boxes and
the corresponding measured values in each of the Measured Value
edit boxes (The measured values are the values displayed by
MultiLab when measuring the two real values
5. Click OK
The calibrated sensor parameters will be saved in MultiLab.
To reset to the default calibration for any sensor, select the sensor and click Restore
defaults.
104 Chapter 4 Working with a desktop computer
