4.7.7.

The Analysis Wizard

1.Using the Analysis Wizard

The analysis wizard will guide you through the various analysis functions available in
the MultiLab program. The analysis functions are grouped into three main categories:
curve fit (regression), averaging, and mathematical and trigonometric functions.
To apply an analysis function to a data set:
1. Use the cursors to select the graph or data range to which you would
like to apply the analysis
2. Click Analysis Wizard
3. Click a category tab:
a. Curve fit
b. Averaging
c. Functions

2.Curve fit

1. Select a fit type by clicking its icon (If you choose polynomial fit,
select the order you want)
2. If you use the cursor to select a data set, it will be highlighted in the
Based on data set list, but you have the option of selecting a
different data set
3. Type a name in the Name box (optional - the default name includes
both the function and the data set names).
on the main toolbar
Figure 16: Analysis wizard – curve fit
Chapter 4 Working with a desktop computer 109
