3. Click Video Analysis
Motion Analyzer module
4. Click Capture new movie
5. To begin recording click Record
toolbar
6. To finish recording click Stop
7. Click Analyze movie
MultiLab prompts to save the movie before processing it.

2.From an external source through a video board

Many video capture boards offer video-in/video-out features. A video capture card
can be used with a wide variety of video sources and through a number of digital
connections. Video from a VCR or video camera can be captured through video-out
ports.
To capture video from a videotape through a VCR:
1. Insert the tape into the VCR. Go to the point you want to capture and
then stop the tape.
2. Find the video-out on the back of the VCR and connect one end of
the appropriate cable. Connect the other end of the cable to the
video-in on your video capture board.
3. Click Video on the menu bar, then click Enable video
4. Click Video Analysis
Motion Analyzer module
5. Click Capture new movie
6. To begin capturing click Record
toolbar
7. Play the video. Make sure that you start the video after you start the
capture to make sure nothing gets cut off from the beginning
8. To finish capturing stop the VCR and click Stop
9. Click Analyze movie
MultiLab prompts to save the movie before processing it.
on the main toolbar to open the Video
on the Video Motion Analyzer toolbar
on the Capture new movie
to begin capturing position and time
on the main toolbar to open the Video
on the Video Motion Analyzer toolbar
on the Capture new movie
to begin capturing position and time
Chapter 4 Working with a desktop computer 121
