You can define the properties of each sensor individually in the first step of the Setup
wizard, or by selecting Sensor properties from the Logger menu.
1. Click Setup wizard
wizard
2. Click Properties
3. Click the check boxes next to the desired measurements
4. To change more properties, click the tab at the top of the dialog box
5. Click OK

3. Presetting the display

You may want to define the graph's settings, such as formatting and scaling the
graph and selecting the axes, and to define the meters' settings prior to beginning a
recording session. You can define the settings of each sensor input individually in the
first step of the Setup wizard:
1. Click Setup Wizard
wizard
2. Click Properties
3. Click the Display properties tab
4. Select a measurement from the Select measurement drop list
5. Select the graph or graphs in which you would like to display the
data, from the Display on graph drop list
6. Select a meter in the Meter type drop list if you want to display the
data in a meter as well as on the graph
7. Format the line and markers in the Plot section
8. If you want a specific scale, uncheck the Auto scale check box and
enter the desired minimum and maximum values of the axis
9. Click OK

4.Preset the graph's X-axis

1. Click X-Axis display properties in the first step of the Setup wizard
to open the dialog box:
on the main toolbar to open the Setup
next to the input you want to set
on the main toolbar to open the setup
next to the input you want to set
Chapter 4 Working with a desktop computer 101
