3.9. Toolbar buttons

3.9.1.

Main toolbar

Run
Stop
Setup
Data Map
Graph
Table
Meter
3.9.2.

Graph toolbar

Zoom in
Zoom out
Zoom to selection
Auto scale
st
1 Cursor
nd
2 Cursor
Move right
Move left
Scroll right
Scroll left
3.9.3.

Meter toolbar

Analog
Bar
Digital
Begin collecting data
Stop collecting data
Set up TriLink
Display the Data Map
Display the Graph
Display the Table
Display a Meter
Zoom in around a selected point or in to a selected range
Reverse the most recent zoom operation
Zoom in to a selected area
Display all the data
Display or remove the first cursor
Display or remove the second cursor
Move the cursor one point to the right
Move the cursor one point to the left
Scroll the graph one page to the right
Scroll the graph one page to the left
Display an analog meter
Display a bar meter
Display a digital meter
Chapter 4 Chapter 3 Working with Pocket PC 73
