3.5.2.

Start Recording

Click Run on the main toolbar. Click the down arrow to change the
recording mode.
3.5.3.

Stop Recording

Click Stop on the main toolbar
3.5.4.

Clear TriLog's Memory

To erase all experiment data currently stored in the TriLog, click Clear memory in
the Logger menu (TriLog must first be connected to the PC).
3.5.5.

Select TriLog's operating mode

To enable TriLog's Auto ID mode (see on page 12):
1. Connect TriLog to the PC
2. Click Logger on the menu button, then click Auto ID
To switch to 8 sensors click Logger on the menu bar then click Auto ID a second
time to uncheck the Auto ID option.
3.5.6.

Calibrating the sensors

MultiLab enables you to calibrate any of the sensors manually. This calibration is
much more accurate than the calibration performed by TriLog. With MultiLab, you
can calibrate the sensor using two points instead of the "one point automatic offset
calibration" used by TriLog:
1. Connect TriLog to the PC
2. Select the Calibrate sensors option from the Logger menu
3. Choose a sensor from the Select sensor drop list and click OK
4. Click on the Calibration tab
5. Enter a distinct real value in each of the Real Value edit boxes and
the corresponding measured values in each of the Measured Value
edit boxes (The measured values are the values displayed by
MultiLab when measuring the two real values
6. Click OK
The calibrated sensor parameters will be saved, so there is no need to calibrate
TriLog every time you run the MultiLab program.
To reset to the default calibration for any sensor, select the sensor and click Restore
defaults.
Chapter 3 Working with MultiLab 71
