Chapter 3
Working with MultiLab

3.1. Install the Software

3.1.1.

System Requirements

To work with MultiLab, your system should be equipped with the following:
1.Software
! Windows 95 or later (Windows 95 and Windows NT will not support
video recording)
! Internet Explorer 5.0 or later (you can install Internet Explorer 5 when
you install MultiLab, since it ships with the product)
2.Hardware
Pentium II 300MHz or higher (Pentium 200MHz or higher without
!
video recording)
32 MB RAM (64 MB recommended)
!
! 10 MB available disk space for the MultiLab application (50 MB to
install the supporting applications)
! To work with the video window your system should be equipped with a
video camera.
! To be able to record and play voice comments your system should be
equipped with a sound card, a microphone and a speaker.
3.1.2.

Installation

Insert the CD into your CD drive.
Installation will begin automatically. Simply follow the on-screen instructions to
continue.
In case auto run is not working, open My Computer and click on the CD drive folder
(d: drive in most cases) and double-click on the setup icon, then follow the on-screen
instructions.
To uninstall the software: From the Start menu select Settings and click on Control
Panel, then use the Add/Remove programs function to remove the MultiLab
application.
To install the USB driver (optional):
1. Insert the CD into your CD drive. If Installation begins automatically
(and you have already installed MultiLab), click Cancel to stop
installation
2. Connect the TriLog to a USB port on your PC and turn the TriLog on.
Windows will automatically detect the new device and open the Add
New Hardware Wizard
