3. Formatting the table

1. Changing column width
Drag the boundary on the right side of the column heading until the column is the
desired width.
2. Changing row height
Drag the boundary below the row heading until the row is the desired height.
3. Formatting the fonts
1. Click Table properties
2. Select the Font tab
3. Format the font, as well as the font's style and size
4. Click OK
4. Changing units and number format
1. Click Table properties
2. Select the Units tab, and then select the plot you want to format
from the select plot drop list
3. Choose the prefix option you want
4. Select the desired number of decimal places
5. To display numbers in scientific format, check the Scientific check
box
6. Click OK

4. Add a table to the project

MultiLab displays new data in the table window every time you start a new recording.
You can always display previously recorded data using the Edit table dialog. If you
want to save a table that you created to your project, or to update a saved table with
changes you made, use the Add to project tool:
Click Add to project
3.4.4.

Meters

MultiLab enables you to view data in meters format on the screen (one meter for
each sensor), with up to four meters showing at once. The meters can display live
data while MultiLab is recording, or saved data when a saved file is replayed.
When a cursor is displayed, the meter shows the measured values that correspond
to the time of the point at which the cursor is positioned.
There are three meter types: analog, bar and digital. The meter's scaling
automatically matches the graph's scaling.
To set up the meters:
1. Click Meter Setup
on the table toolbar
on the table toolbar
on the table toolbar.
on the main toolbar
Chapter 3 Working with MultiLab
63
