2. Select the meter type, and the data set to be displayed
3. A list entry that begins with a graph number denotes a displayed
data set. A list entry that begins with an input number denotes the
next recording, and will be displayed on the meter the next time you
start a recording
4. Repeat this procedure for up to four meters
5. To remove the meters click Meter Setup
3.4.5.

Data Map

Click Data Map
The data map is a separate window that displays the list of data sets that were
recorded or downloaded in the current session, as well as the lists of all the saved
graphs and tables. Use the Data Map to navigate through the available data sets and
to keep track of the data that is being displayed in the graph window.

1. Control the display with the Data Map

The items in the Data Map are sorted into three main categories:
•
Data sets (including analysis functions)
•
Saved graphs
•
Saved tables
Double click on a category to bring up the full list. Double click a second time to
collapse the list. You can also use the plus (+) and minus (-) signs next to the icons
to expand or collapse the categories.
The Data sets list expands to sub-categories of experiments and functions. To
display the complete list of measurements, or the complete list of analysis functions
performed on the measurements for any individual experiment, double click the
experiment's icon or click the plus sign (+) next to it.
To collapse a list under an individual experiment, double click the experiment's icon
or click the minus sign (-) next to it.
To display a data set or a saved graph in the graph window, or to display a table in
the table window, double click its icon. Double click a second time to remove it.
You can also use a shortcut menu to display or remove a data set from the graph.
Simply right-click an icon, then click display on graph #1 or display on graph #2.
To delete an individual item from the Data Map and from the project, right-click on its
icon and click Delete. To permanently delete the item, click Save
toolbar.
To remove all data sets from the Data Map, right-click the Data sets icon
Clear All Data.

2.Understanding Data Map icons

Data sets list
Functions – includes all the analysis functions of the project
Individual function – currently not on display
64 Chapter 3 Working with MultiLab
to display or remove the Data Map.
, and click Remove all
on the main
and click
