Create A New Project; Import Data - Fourier TriLog User Manual

3.3.7.

Create a New Project

There are three ways to create a new project:
1. Open the MultiLab program, which will open a new file each time
2. When working in Single Measurement mode, a new project is
opened every time you click on the Run button to start a new
recording
3. Any time you click New button
3.3.8.

Import data

Any file that is in comma separated values text format (CSV) can be imported into
MultiLab
To import a CSV file:
1. Click File on the menu bar, then click Import CSV file
2. In the dialog that opens, next to Look in, navigate to the drive and
folder that contains the CSV file
3. Select the file
4. Click Open
Tips:
To create a text file in a spreadsheet:
1. Open a new spreadsheet
2. Enter your data according to the following rules:
a)
b)
See for example the table below:
3. On the File menu, click Save As
4. In the File name box, type a name for the workbook
The first row should contain headers. Each header includes
the name of the data set and units in brackets, e.g.
Distance (m)
The first column should be the time. The time interval
between successive rows must match the time intervals
accepted by MultiLab. You can export MultiLab files to
Excel to learn about these time formats
Chapter 3 Working with MultiLab
on the toolbar
55
