4. Select total number of samples
Press the SAMPLES button to display the current total number of recording points:
The cycle of sample points is moved through by pressing the SAMPLES button until
the appropriate number of points is found.
5. Start recording
Press the RUN button to start recording.
The LCD screen will display:
At rates of up to 10 samples per second TriLog displays the recorded data values,
the number of the last recorded data sample, and the total number of samples. Use
the RATE button to scroll through the different sensor's data and the number of
samples.
You can stop recording any time by pressing the RUN button a second time.
Otherwise logging will stop after the selected number of samples where taken. The
LCD screen will display the number of the experiment in TriLog's memory:
1.2.4.

Working with the TriLog keypad

Press for one second to turn TriLog on. Press a second time to
On / Off
turn it off
Note: Pressing OFF will not erase the sample memory. The data stored
in the memory will be kept for up to 10 years.
When programming TriLog press to scroll to the desired recording
rate.
Rate
When TriLog is running (in rates up to 10/s) use this button to
scroll through the different data displays
When programming TriLog press to scroll to the desired number of
recording samples.
Samples
When TriLog is running in manual mode press this button each
time you want to collect a sample
Press to begin recording. Press a second time to stop
Run
14 Chapter 1 TriLog
_ _ _ _ SAMPLES_ _ _ _ _
S = 500
Logging
_ _ _ LOGGER – RUN _ _ _
Log 01 ended
