internal rechargeable 2.4V NiMH battery, external 6V DC input
Operating temperature range: 0°C to 50°C
!
! Dimensions: 115 x 70 x 28mm
! Weight: 160gr
! Standards compliance: CE, FCC
2.

Sensors

! Acceleration (DT138)
! Angular Position (DT031)
! Breathing (DT037)
Colorimeter (DT185)
!
! Conductivity (DT035)
! Control Switch (DT110/111)
! Current ±2.5A (DT005)
! Current ±250mA (DT006)
! Current 0 to 20mA (DT007)
! Distance 0.4 to 6m (DT187)
EKG (DT048)
!
Force ±10N, ±50N (DT120)
!
! Geiger-Muller Counter (DT116)
! Heart Rate (DT155)
! Heat Flow (DT032)
! Humidity (DT014)
! Light 0 to 130klx (DT010)
! Light 0 to 300lx (DT009-1)
! Light 0 to 600lx, 6000lx and
150klx (DT009-4)
! Light 0 to 6.6 lx (DT009)
! Magnetic Field ±10mT, ±0.2mT
(DT028)
! Microphone (DT008)
! Oxygen (DT222A)
3.

Accessories

DT 225 - Input Splitter
! Splits one input into two.
! Enables simultaneous use of 8 inputs (analog or digital).
DT 224 - Sensor Cable
! Connects TriLog to sensors
DT 023 -VERNIER Sensor Adaptor
! Enables the connection of all VERNIER analog sensors (with DIN plugs) to TriLog.
For further information please contact your local TriLog dealer.
110 Chapter 5 Specifications
! PH (DT016)
! Photo Gate (DT137)
! Pressure 0 to 10 kPa (DT015-2)
! Pressure 0 to 700 kPa
(DT015-1)
! Pressure Mat (DT033)
Rain collector (AC013)
!
! Rotary Motion (DT148)
! Smart Pulley (DT122)
! Temperature 0° C to 1250° C
(DT025)
Temperature 0°C to 750°C
!
(DT026)
! Temperature -200°C to 400°C
(DT027)
Temperature -25° C to 110°C
!
(DT029)
! Turbidity (DT095)
! Voltage ±2.5 V (DT002)
! Voltage ±25 V (DT001)
! Voltage ±50mV (DT004)
! Voltage 0 to 5 V (DT003)
! Voltage leads 0 to 5V (DT228)
! Wind speed and direction (AC012)
