not transmitted to the PC until the recording period has ended, when the data is
automatically downloaded to the PC and displayed.
Off-line data logging
To download data that was recorded offline, or while TriLog was not connected to a
PC, connect TriLog to the computer, run the MultiLab program and click Download
on the toolbar. This will initiate the Post-Experiment Data Transfer
communication mode. Once the transfer is complete, the data will be displayed
automatically in the graph window and in the table window. If there are several
experiments stored in the TriLog, the first download will bring up the most recent
experiment; the second download will bring up the second most recent experiment,
and so on.
To download a particular experiment, choose Selective download from the Logger
menu, then select the experiment's number in the Download dialog box.
Click Cancel in the Download progress window at any time to stop downloading the
data.
3.3.5.

Save Data

Click Save on the main toolbar to save your project. This will save all the data
sets, graphs, tables and video movies under one project file.
Saving the project will also save any special formatting and scaling you did.
If you made any changes to a previously saved project, click Save to update the
saved file or select Save as... from the file menu to save it under another name.
Note:
To delete a specific data set, a graph or a table from the project, use the
Data Map (see page 64)
To remove unwanted data from a specific data set, apply the crop tool
(see page 89).
3.3.6.

Open a File

1. Click Open
2. Navigate to the folder in which the project is stored
3. Double click the file name to open the project
MultiLab opens the project and displays the first graph on the graph list. If the project
does not include saved graphs, the file opens with an empty graph window. Use the
Data Map (see page 64) to display the desired data set.
54 Chapter 3 Working with MultiLab
on the main toolbar
