5. To select a data set for display on the X-axis, click on the data set's
name in the X-axis list. You can only select one data set at a time for
the X-axis
6. Type in the title of the graph in the Graph title edit box (optional)
7. Click OK

6.Format the graph

You can change the data line's color, style and width. You can also add markers that
represent the data points on the graph and format their style and color.
The color of the Y-axis matches the corresponding plot's color and will automatically
change with any change made to the color of the corresponding plot.
1. Click Graph properties
properties dialog box
2. Select the Lines tab, and then select the plot or axis you want to
format in the Select plot drop list
3. From here you can format the line's color, style and width, as well as
the markers' color and style. To remove the line or the marker,
uncheck the corresponding Visible check box
4. Click OK
5. To restore the default formatting, click Restore default

7. Change the graph's units and its number format

1. Click Graph properties
properties dialog box
2. Select the Units tab, and then select the plot or axis you want to
format in the select plot drop list
3. Choose the prefix option you want
4. Select the desired number of decimal places
5. To display numbers in scientific format, check the Scientific check
box
6. Click OK

8. Add a graph to the project

MultiLab displays new data in the graph window every time you start a new
recording. You can always display previous data using the Edit graph dialog box or
by double-clicking on the data's icon in the Data Map. If you want to save a graph
that you created to your project, or to update a saved graph with changes you made,
use the Add to project tool:
Click Add to project
on the graph toolbar to open the Graph
on the graph toolbar to open the graph
on the graph toolbar.
Chapter 3 Working with MultiLab 61
