Cirrus Logic Crystal CS8427 Series Preliminary Product Information page 48

28L TSSOP (4.4 mm BODY) PACKAGE DRAWING
N
1 2 3
TOP VIEW
DIM
A
A1
A2
b
D
E
E1
e
L
∝
Notes: 1. "D" and "E1" are reference datums and do not included mold flash or protrusions, but do include mold
mismatch and are measured at the parting line, mold flash or protrusions shall not exceed 0.20 mm per
side.
2. Dimension "b" does not include dambar protrusion/intrusion. Allowable dambar protrusion shall be
0.13 mm total in excess of "b" dimension at maximum material condition. Dambar intrusion shall not
reduce dimension "b" by more than 0.07 mm at least material condition.
3. These dimensions apply to the flat section of the lead between 0.10 and 0.25 mm from lead tips.
48
D
E
e
b
SIDE VIEW
INCHES
MIN
--
0.002
0.034
0.008
0.303
0.248
0.169
--
0.020
0°
A2
A
A1
SEATING
PLANE
MILLIMETERS
MAX MIN
0.043 --
0.006 0.05
0.037 0.85
0.012 0.19
0.311 7.70
0.256 6.30
0.177 4.30
0.026 --
0.028 0.50
8° 0°
CS8427
E1
END VIEW
L
NOTE
MAX
1.10
0.15
0.95
0.30 2,3
7.90 1
6.50
4.50 1
0.65
0.70
8°
∝
DS477PP1
