12. PACKAGE DIMENSIONS

28L SOIC (300 MIL BODY) PACKAGE DRAWING
1
b
SEATING
PLANE
e
DIM
A1
C
D
H
∝
DS477PP1
D
INCHES
MIN
A 0.093
0.004
B 0.013
0.009
0.697
E 0.291
e 0.040
0.394
L 0.016
0°
E H
A1
MILLIMETERS
MAX MIN
0.104 2.35
0.012 0.10
0.020 0.33
0.013 0.23
0.713 17.70
0.299 7.40
0.060 1.02
0.419 10.00
0.050 0.40
8° 0°
CS8427
c
L
A
MAX
2.65
0.30
0.51
0.32
18.10
7.60
1.52
10.65
1.27
8°
∝
47
